Home > Ventilation Duct Fan >

Dual Direction Ventilation Duct Fan

Product Categories
Foshan Nanhai Nanyang Electric Appliance & Motor Co., Ltd.
Contact Now

Dual Direction Ventilation Duct Fan

  • 1
  • 2

Brand Name : NANYOO / OEM / ODM

Model Number : DUT15-32(D)

Certification : CE / CB / CCC

Place of Origin : China

MOQ : 1 unit

Price : Negotiated

Payment Terms : L/C, T/T, Western Union

Supply Ability : 15000 per month

Delivery Time : 30-35 work days

Packaging Details : As per factory standard

Product name : Ventilation duct fan

Type : duct fan,fan ventilation duct fan

Voltage : 220V,110-230V,60hz ，50hz

Electric current type : AC

Blade material : Mile Steel / Aluminum Alloy / Stainless Steel

Mounting : Free Standing , Duct Fan , Wall Fan , Ceiling Fan

Air volume : 250 -360CFM

Power : 59 -70 W

Contact Now

Dual Direction Square Ventilation Duct Fan Intake And Outlet Work Together

Thin Body Satisfies The Installation In Different Places

Dual Direction Ventilation Duct Fan

FEATURES

Intake and outlet work together

Thin body satisfies the installation in different places

With filter for enjoying the fresh air



PRODUCT DESCRIPTION / SPECIFICATION

Model A B C D E F G H I J X J K
DUT10-24(D) 500 480 420 528 240 100 65 38 103 500X500 201
DUT15-32(D) 500 480 420 528 243 150 74 38 120 500X500 241
DUT15-42(D) 600 540 520 588 270 150 74 38 140 600X600 281
DUT20-54(D) 690 750 733 677 373 200 65 23 156 322X311 322
DUT25-66(D) 800 822 843 748 403 250 75 23 190 400X340 437
DUT25-76(D) 800 822 843 748 403 250 75 23 190 400X340 437


Dual Direction Ventilation Duct Fan



Model A B C D E F x F G x G
DUT30-86(D) 900 1180 1223 818 588 396 x 331 548 x 386
DUT40-87(D) 900 1180 1223 818 588 548 x 386

548 X 386
Model H I J K x K L x L M N
DUT30-86(D) 26 218 175 440 x 380 440 x 190 437 48
DUT40-87(D) 26 218 175 440 x 380 440 x 190 437 48

Dual Direction Ventilation Duct Fan

Voltage/Frequency  220-240V/50Hz , or 110V/60Hz ,  110V/50Hz , 220V/60Hz are all available

Dual Direction Ventilation Duct Fan

Model Power Air
Volume		 Static Pressure Noise Net
Weight		 Gross
Weight		 Carton
Size		 Remark
(W) (m³/h)/CFM (Pa) (dB) (KG) (KG) (mm)
DUT10-24(D) 105/85 180/106 100/59 210/110 45-36 18.9 20.1 666 x 570 x 260 Without Filter (With Filter)
DUT15-32(D) 70/59 360/212 250/147 160/130 50-39 24.1 25.5 666 x 570 x 300 Without Filter (With Filter)
DUT15-42(D) 165/155 500/294 400/235 210/190 52-44 17.9 29.5 766 x 629 x 340 Without Filter (With Filter)
DUT20-54(D) 420/400 1000/588 800/470 320/270 58-54 39.2 41 868 x 840 x 395 Without Filter (With Filter)
DUT25-66(D) 700/590 1500/882 1200/706 350/320 60-58 53.4 58.7 948 x 839 x 380 Without Filter (With Filter)
DUT25-76(D) 960/650 2000/1176 1500/882 360/350 65-61 53.4 58.7 948 x 839 x 380 Without Filter (With Filter)
DUT30-86(D) 1470/850 2600/1529 1700/1000 440/305 82-62 53.4 58.7 948 x 839 x 380 Without Filter (With Filter)
DUT40-87(D) 2400/2180 3800/2235 2800/1647 460/330 90-82 53.4 58.7 948 x 839 x 380 Without Filter  With Filter)
